Vampyrophrya pelagica (Chatton and Lwoff 1930), an apostome ciliate infectious on calanoid copepod from the Northeastern Arabian Sea



Zooplankton provides a dynamic habitat to various kinds of epibionts in the marine ecosystem and also forms a source of food and nutrients to various parasites and parasitoids. The study was conducted to identify the association of ciliates with calanoid copepod of Northeastern Arabian Sea. Zooplankton samples collected were analysed under stereomicroscope for any kind of ciliate attachments. The infective stage and major characteristics of the ciliates were discussed. The present observation is the first report of apostome ciliate Vampyrophrya pelagica on calanoid copepod Bestiolina similis from the open ocean waters off Tarapur, Northeastern Arabian Sea, during the early spring intermonsoon season and also a new host record for the ciliate.


Analysis of ~ 2530 copepod revealed the presence of 12 copepod specimens infested with apostome ciliate Vampyrophrya pelagica. All the host copepod, identified as Bestiolina similis, were females. Approximately 50–60 ciliates occupied the host endocuticular region. V. pelagica was represented by fully grown trophont stage characterized by the presence of a large food vacuole surrounded by a thin layer of cytoplasm with numerous lipid bodies.


The study establishes a new host record, calanoid copepod B. similis for V. pelagica. The report is the first of its kind from the Indian waters and extends the biogeographic boundary of the apostome ciliate.


Marine zooplankton provides a diverse and dynamic substratum to various kinds of epibionts in the vast range of water column and also forms a source of food and nutrients to various parasites and parasitoids. Zooplankton, the heterotrophic link between the phytoplankton and organisms of higher trophic level, are primarily associated with many different kinds of ecto and endoparasites/symbionts. Pelagic copepods, most numerous among the zooplankton, form a major substratum for almost all organisms of lower trophic level such as bacteria, ciliates, diatoms, dinoflagellates, platyhelminthes, nematodes and other crustaceans in the aquatic ecosystem. Some of these organisms infect copepod as intermediate or final hosts, while others become parasitoids and consume them. The exploration of symbionts among the marine zooplankton has been very inadequately understood, so that symbiosis is considered to be of minor importance in the ecological interactions structuring the pelagic ecosystem (Ohtsuka et al., 2007). Only recently, detailed investigations on various symbiotic associations have revealed the complex and significant influence of the association and the associates on population dynamics of the host zooplankton (Cachon & Cachon, 1987; Capriulo et al., 1991; Coats & Heisler, 1989; Ohtsuka et al., 2004, 2007; Skovgaard & Saiz, 2006).

Protozoans predominantly, members of Phylum Ciliophora, and subclasses Apostomatia, Suctoria, Hymenostomata, Peritricha and Spirotricha (Corliss, 1979) form very common epibiont on the exoskeleton of zooplankton crustaceans, especially copepods. Among these, subclass Suctoria and Peritricha are the most widely reported epibionts of marine copepods. Apostomes, followed by Suctoria and Peritricha, are ciliates that are symbiotic on both planktonic and benthic crustaceans, mainly copepods, as well as on ostracods, gammarids, isopods, caprellids, euphausiids and decapods (Bradbury, Capriulo & Small, 1986; Capriulo et al., 1991; Chatton & Lwoff, 1935; Gómez-Gutiérrez et al., 2003; Kudo, 1966; Lindley, 1978) and are rarely found on cnidarians (Kudo, 1966; Bradbury 1974b), ctenophores (Kudo, 1966; Skovgaard, 2014), echinoderms (Bradbury 1974b), annelids (Kudo, 1966), chaetognaths (Skovgaard, 2014) and even on other apostomes (Kudo, 1966). Considering the high prevalence of apostome on copepod and its direct influence on their predators, the histophagous feeding of apostome ciliates is relevant towards both the detritus and grazing food chain. The rapid consumption of the host tissues by the ciliate after the injury or predation reduces the nutrient absorption by the predators and hence affect the quality and quantity of detritus matter produced by the host, thus playing an important role in biogeochemical cycling in the aquatic ecosystem (Ohtsuka et al., 2004). Apostome ciliates increase the mortality rate of copepods, consequently reducing the prey availability to carnivorous zooplankton and other higher trophic level organisms in the ecosystem. Apostomes are common along the coasts of the USA, France and Japan, but only a little attention has been given towards their presence in other areas. A major contribution towards the life cycle, morphology and taxonomy of apostome ciliates was made by Chatton and Lwoff (1935). Several studies are still being carried out to understand the apostome host specificity, ecology and their impact on the marine ecosystem in the field. Typical apostome genera include Vampyrophrya, Gymnodiniodes and Hyalophysa (Lynn, 2008), of which Vampyrophrya has been widely discovered as symbionts on copepod hosts around the world.

Vampyrophrya pelagica, a common copepod parasite, plays an important role in brackish to coastal pelagic waters of world oceans due to its prevalence and harmful effects on copepods and other invertebrate predators of copepods such as chaetognath, ctenophores and medusa. They have relatively low host specificity and are highly prevalent during warm water seasons. Being a histotrophic apostome, V. pelagica possess a large cytostome for engulfing partially digested host tissues (Chatton & Lwoff, 1935; Grimes & Bradbury, 1992; Ohtsuka et al., 2004). Significant contributions to the study of the life cycle, host specificity and seasonal and distributional occurrences of V. pelagica were given by Grimes and Bradbury (1992) from North Carolina, Atlantic Ocean, Ohtsuka et al. (2004) from the Seto Inland Sea, Pacific Ocean and potentially high diversity of apostomes on copepod in the Chinese waters (Guo et al., 2012). Ohtsuka et al. (2004) described the morphological observations, attachments sites, prevalence and intensity, seasonal occurrence and host and stage specificity in the apostome ciliate, V. pelagica in the Seto Inland Sea, Japan.

The present study is the first report of apostome ciliate Vampyrophrya pelagica on calanoid copepod Bestiolina similis from the open ocean waters off Tarapur, Northeastern Arabian Sea, during the early spring intermonsoon season.


Copepods infected with apostome ciliates were observed in the surface mesozooplankton samples collected from the open ocean waters off Tarapur (Northeastern Arabian Sea- NEAS, Fig. 1), onboard FORV Sagar Sampada during the early spring intermonsoon season (March 2013). The sampling was done at 21 locations (0, 10, 20, 30, 40, 50, 75, 100 and 120 m depth) along the transects, viz. off Okha, off Veraval, off Tarapur, off Mumbai and off Ratnagiri. Vertical profiling of physical and chemical parameters such as temperature, salinity, dissolved oxygen and density was obtained using Conductivity-Temperature-Depth profiler (CTD, Sea-Bird Electronics model 911 series, Sea-Bird Inc.). Chlorophyll a measurements were taken spectrophotometrically (Parsons et al., 1984) using a UV–Visible spectrophotometer. Phytoplankton samples were collected by filtering ~ 50 L of surface water through 20μ bolting silk. The concentrate was then preserved in 1–3% neutralized formaldehyde solution. Quantitative and qualitative estimation of phytoplankton was done using Sedgewick rafter counting cell following standard identification keys (Tomas, 1997). Surface mesozooplankton samples were collected by the oblique hauling of bongo net (200µ) from the twenty-one stations along the NEAS. Zooplankton samples collected were analysed under a stereomicroscope for copepod infected with ciliates. Individuals were picked up with a Pasteur pipette and preserved in 5% neutralized formaldehyde solution for further analysis and identification. Ciliates were measured and photographed for light microscopy (LM) using Nikon Eclipse light microscope attached with Nikon DN 100 series digital camera and identified following standard keys (Chatton & Lwoff, 1935; Grimes & Bradbury, 1992; Ohtsuka et al., 2004). The copepods were examined under a stereoscopic microscope (Leica MZ16) and identified following Al-Yamani et al. (2011).

Fig. 1
figure 1

Study area. Red dot represents the station from where the apostome ciliate Vampyrophrya pelagica was found in copepod


The mesozooplankton assemblage along the open ocean waters off Tarapur, Northeastern Arabian Sea, was dominated by more than 80% of copepods followed, in dominance, by other planktonic groups such as siphonophores, salps, chaetognaths, mysids, tunicates, fish eggs and decapods during the early spring intermonsoon season of March 2013. Out of the 21 stations sampled, only one station (Lat. 20° 37.73′ N; Long. 68° 24.21′ E) off Tarapur observed the presence of ciliate infested copepod. The copepod population of the particular station was dominated by Bestiolina similis, followed by other species such as Acartia spp., Paracalanus aculeatus and Eucalanus spp. Analysis of ~ 2530 copepod specimens along the respective station showed 12 copepod specimens infested with apostome ciliate Vampyrophrya pelagica. The host calanoid copepod was identified as Bestiolina similis, with all the host organisms being female. Figure 2 shows the copepod host infested with ciliate. V. pelagica, a histotrophic apostome, was represented by the fully grown trophont stage. It is characterized by the presence of a large food vacuole surrounded by a thin layer of cytoplasm with numerous lipid bodies (Fig. 3). The apostome ciliate occupied the endocuticle region of the hosts and fed on the host’s tissue. Approximately 50 to 60 apostome ciliates were present in each host copepod.

The physiochemical parameter along the station of occurrence of V. pelagica in the Northeastern Arabian Sea during the early spring intermonsoon is shown in Table 1. Temperature, salinity and dissolved oxygen along the station were observed to be 26.2 °C, 36.47 psu and 4.4 ml L−1, respectively. The chlorophyll a concentration was measured to be 0.78 µg L−1. The station was observed to be non-productive with common diatom species, including Coscinodiscus sp., Thalassiosira sp., Skeletonema sp., Chaetoceros sp., Thalassionema sp., Nitzschia sp., Odontella sp. and dinoflagellate Noctiluca scintillans.

Fig. 2
figure 2

Copepod Bestiolina similis infested with apostome ciliate Vampyrophrya pelagica LM (Scale bar: 100 μm)

Fig. 3
figure 3

Magnified view of V. pelagica inside the host copepod LM (Scale bar: 50 μm)

Table 1 Physicochemical parameters of the area where the apostome ciliate, Vampyrophrya pelagica, was observed in copepod Bestiolina similis


Vampyrophrya pelagica Chatton & Lwoff, 1930

Kingdom :


Phylum :


Subphylum :


Infraphylum :


Class :


Subclass :


Order :


Family :


Genus :


Species :

V. pelagica

Vampyrophrya pelagica, first described by Chatton and Lwoff (1930), is a well-investigated histotrophic apostome in its morphology, cytology and ecology. According to Grimes and Bradbury (1992), Ohtsuka et al. (2004), Ohtsuka et al. (2011) and Ohtsuka et al. (2015), there are four functionally different stages in the life cycle of V. pelagica. It includes phoront (resting stage), trophont (feeding stage), tomont (division stage) and tomite (infective stage). The phoront are oval, dormant, encysted stage on the body surface of the host. They are mainly attached to the ventral side and appendages of prosome region of copepod by means of a short stalk of ~ 5 µm length. The site of attachment is highly influenced by the feeding and swimming current created by the host copepod. Phoront stage is characterized by specialized intracellular structure, numerous lamellae, which were identified as the precursor of the food vacuole membrane of the trophont. These phoront excyst in two ways: either by a physical injury to the host (single-host cycle) or the predation of apostome infected copepod by invertebrate predators such as chaetognath, medusa, ctenophore (two-host cycle) or rarely due to unsuccessful moulting (Grimes & Bradbury, 1992; Ohtsuka et al., 2004). In any condition, the trigger for phoront hatching, a critical point in the life cycle, is the oozing body fluid of the copepod. Trophont, excysted from the phoront, is the feeding stage. It is characterized by the presence of an expanded food vacuole that occupies most of the cytoplasm, pushing the macronucleus and other organelles to the edges. Numerous lipid bodies are also sparsely distributed in the cytoplasm. Trophont enters through the wound into the host body and consumes the entire host tissue with the help of its large cytostome. The cell volume increases 30 times the initial trophont size. The fully grown trophont then settles in the cuticle of the totally consumed/dead copepod and metamorphose into encysted tomont. The tomont undergo palintomy, and up to 2 to 32 tomites are released from a tomont. These tomites form the infective stage and search for new copepod host. Once on the new host, they again settle and metamorphose to form encysted phoront.

The host specificity of V. pelagica is considerably low, but they prefer calanoid to cyclopoid copepods. Table 2 gives the details of the previously reported copepod host of V. pelagica. Various reports suggest that calanoid and poecilostomatoid copepods are the most preferred (Boxshall & Halsey, 2004) along with cyclopoid and harpacticoid copepods (Ohtsuka et al., 2004) irrespective of their size, sex and behaviour. The major copepod host includes Parvocalanus parvus, Calanus sinicus, Euterpina acutiformes, Corycaeus affinis from the Seto Inland Sea, Japan (Ohtsuka et al., 2004), Centropagus hamatus, C. typicus, Acartia tonsa, A. longiremis, Corycaeus sp., Eurytemora sp., Labidocera aestiva, Eucalanus sp., Paracalanus sp., Oncaea minuta from North Carolina, Atlantic ocean (Grimes & Bradbury, 1992). Despite having a large host range belonging to calanoid, cyclopoid and harpacticoid copepods, there are exceptions where certain copepods included within the same genus such as the cyclopoid Oithona and harpacticoid Microsetella norvegica, are rejected by the apostome ciliate (Ohtsuka et al., 2004, 2015). The tomites are observed to crawl around these un-preferred copepods to seek attachment sites but finally swim away from the water (Ohtsuka et al., 2015). The present study establishes a new host, calanoid copepod Bestiolina similis for V. pelagica from the Northeastern Arabian Sea, which inflicts the host specificity of the apostome ciliate towards the calanoid copepods. Also, the high dominance of the females of B. similis along off Tarapur might be a reason for all the host copepods being similar. This report, thus, extends the biogeographic distribution of V. pelagica to the Northeastern Arabian Sea apart from North Atlantic and Pacific Ocean (Grimes & Bradbury, 1992; Ohtsuka et al., 2004). The naupliar and copepodite stages are also observed to be infected with the phoront (Ohtsuka et al., 2004); however, the phoront are cast-off after the moulting of the juvenile copepods.

Table 2 Summary of previous information on Vampyrophrya pelagica

V. pelagica parasitizes the planktonic copepods and are considered to be pathogenic towards their host. The species infecting the marine copepods kills the injured copepod by partially or entirely consuming their tissues (histophagous feeding) and greatly influences the population dynamics of copepods and their invertebrate predators like chaetognath, medusa and ctenophores. Physically wounded copepod trigger the excystation of the phoront, leading to consumption by the trophont. Since V. pelagica lives at the host’s expense and eventually kills the host, they are considered more as a parasitoid rather than as a parasite (Ohtsuka et al., 2015). The apostome-infected copepod, when ingested by their invertebrate predators, are resistant to the predators digestive enzymes. The predators, thus, fail to digest and absorb nourishment as the ingested copepod are consumed prior by the trophont rather than by the predators (Grimes & Bradbury, 1992; Ohtsuka et al., 2004, 2015). Thus, an increase in the V. pelagica infestation can decrease the copepod abundance and other invertebrate predators (Ohtsuka et al., 2004), thereby influencing the population dynamics of zooplankton and higher trophic level organisms in the water column.


Apostome ciliates have been mainly investigated from the Pacific Ocean, Atlantic Ocean and Chinese waters. In contrast, only fewer studies have been carried out in other areas. The present study, thereby, summarizes the presence and description of apostome ciliate, Vampyrophrya pelagica, collected from the open ocean waters off Tarapur, Northeastern Arabian Sea on calanoid copepod Bestiolina similis, which is a new basibiont record. So far, there is no published report of this parasitic association in the Indian waters, and therefore, this is the first report of V. pelagica in the Northeastern Arabian Sea. This report also extends the biogeographic boundary of the ciliate to NEAS. However, further studies are still required to understand the life cycle, negative impacts on the host and the role of these associations in the vast marine ecosystem.

Availability of data and materials

Data sharing is not applicable to this article as no datasets were generated or analysed during the current study.



United States of America


Northeastern Arabian Sea


Fishery oceanographic research vessel






Light microscopy






Practical salinity unit

ml L−1 :

Millilitres per litre

µg L−1 :

Micrograms per litre






  • Al-Yamani, F. Y., Skryabin, V., Gubanova, A., Khvorov, S., & Prusova, I. (2011). Marine zooplankton practical guide (p. 399). Kuwait Institute for Scientific Research.

    Google Scholar

  • Boxshall, G. A., & Halsey, S. H. (2004). An introduction to copepod diversity (p. 966). Ray Society London.

    Google Scholar

  • Bradbury, P. C. (1966a). The life cycle and morphology of the apostomatous ciliate, Hyalophysa chattoni n. g., n. sp. Journal of Protozoology, 13, 209–225.

    Article  Google Scholar

  • Bradbury, P. C. (1966b). The fine structure of the mature tomite of Hyalophysa chattoni. Journal of Protozoology, 13, 591–607.

    Article  Google Scholar

  • Bradbury, P. C. (1974). Stored membranes associated with feeding in apostome trophonts with different diets. Protistologica, 10, 533–542.

    Google Scholar

  • Bradbury, P. C. (1996). Parasitic ciliates. In K. Hausmann & P. C. Bradbury (Eds.), Ciliates (pp. 463–477). Gustav Fisher.

    Google Scholar

  • Cachon, J., & Cachon, M. (1987). Parasitic dinoflagellates. In E. J. R. Taylor (Ed.), The biology of dinoflagellates (pp. 571–610). Blackwell Sci Publ.

    Google Scholar

  • Capriulo, G. M., Pedone, M. J., & Small, E. B. (1991). High apostomes ciliate endoparasite infection rates found in the Bering Sea euphausiids Thysanoessa inermis. Marine Ecology Progress Series, 72, 203–204.

    Article  Google Scholar

  • Capriulo, G. M., & Small, E. B. (1986). Discovery of an apostomes ciliate (Collinia beringensis n. sp.) endoparasitic in the Bering Sea euphausiids Thysanoessa inermis. Diseases of Aquatic Organisms, 1, 141–146.

    Article  Google Scholar

  • Chatton, E., & Lwoff, A. (1930). Imprégnation, par diffusion argentique, de l’infraciliature des ciliésmarins et d’eaudouce, après fixation cytologique et sans dessication. Comptes Rendus Societe Biologie, 104, 834–836.

    Google Scholar

  • Chatton, E., & Lwoff, A. (1935). Les ciliés apostomes 1. Aperçuhistoriqueetgénéral; etude monographique des genres et des espèces. Archives De Zoologie Expérimentale Et Générale, 77, 1–453.

    Google Scholar

  • Coats, D. W., & Heisler, J. J. (1989). Spatial and temporal occurrence of the parasitic dinoflagellate Duboscquella cachoni and its tintinnine host Eutintinnus pectinis in Chesapeake Bay. Marine Biology, 101, 401–409.

    Article  Google Scholar

  • Corliss, J. O. (1979). The ciliated protozoa: Characterization, classification, and guide to the literature (p. 455). Pergamon Press.

    Google Scholar

  • Gómez-Gutiérrez, J., Peterson, W. T., Robertis, A. D., & Brodeur, R. D. (2003). Mass mortality of krill caused by parasitoid ciliates. Science, 301, 339.

    Article  Google Scholar

  • Grimes, B. H., & Bradbury, P. C. (1992). The biology of Vampyrophrya pelagica (Chatton & Lwoff, 1930), a histophagous apostomes ciliate associated with marine calanoid copepods. Journal of Protozoology, 39, 65–79.

    Article  Google Scholar

  • Guo, Z., Liu, S., Hu, S., Li, T., Huang, Y., Liu, G., Zhang, H., & Lin, S. (2012). Prevalent ciliate symbiosis on copepods; high genetic diversity and wide distribution detected using small subunit ribosomal RNA gene. PLoS ONE, 7(9), e44847.

    Article  CAS  Google Scholar

  • Hockin, D. C. (1984). Records of symbiotic Protozoa from harpacticoid copepods of a sandy beach. Crustaceana, 46(3), 319–320.

    Article  Google Scholar

  • Kudo, R. R. (1966). Protozoology (p. 1174). Springfield.

    Google Scholar

  • Lindley, J. A. (1978). Continuous plankton records: The occurrence of apostome ciliates (Protozoa) on Euphausiacea in the North Atlantic Ocean and North Sea. Marine Biology, 46, 131–136.

    Article  Google Scholar

  • Lynn, D. H. (2008). The ciliated protozoa: Characterization, classification, and guide to the literature (p. 605). Springer.

    Google Scholar

  • Ohtsuka, S., Hanamura, Y., Harada, S., & Shimomura, M. (2007). Recent advances in studies of parasites on mysid crustaceans. Bulletin of the Plankton Society of Japan, 53, 37–44.

    Google Scholar

  • Ohtsuka, S., Hora, M., Suzaki, T., Arikawa, M., Omura, G., & Yamada, K. (2004). Morphology and host specificity of the apostome ciliate Vampyrophrya pelagica infecting pelagic copepods in the Seto Inland Sea, Japan. Marine Ecology Progress Series, 282, 129–142.

    Article  Google Scholar

  • Ohtsuka, S., Horiguchi, T., Hamamura, Y., Yamaguchi, A., Shimomura, M., Suzaki, T., Ishiguro, K., Hanaoka, H., Yamada, K., & Ohtani, S. (2011). Symbiosis of planktonic copepods and mysids with epibionts and parasites in the North Pacific: Diversity and interactions. In A. Asakura (Ed.), New frontiers in crustacean biology (pp. 1–14). Leiden.

    Google Scholar

  • Ohtsuka, S., Suzaki, T., Kanazawa, A., & Ando, M. (2015). Biology of symbiotic Apostome Ciliates: Their diversity and importance in the aquatic ecosystems. In S. Ohtsuka, T. Suzaki, T. Horiguchi, N. Suzuki, & F. Not (Eds.), Marine protists (pp. 441–463). Springer.

    Chapter  Google Scholar

  • Parsons, T. R., Maita, Y., & Lalli, C. M. (1984). A manual of chemical and biological methods for seawater analysis (p. 173). Pergamon Press.

    Google Scholar

  • Skovgaard, A. (2014). Dirty tricks in the plankton: Diversity and role of marine parasitic protists. Acta Protozoologica, 53, 51–62.

    Google Scholar

  • Skovgaard, A., & Saiz, E. (2006). Seasonal occurrence and role of protistan parasites in coastal marine zooplankton. Marine Ecology Progress Series, 327, 37–49.

    Article  Google Scholar

  • Tomas, C. R. (1997). Identifying marine diatoms and dinoflagellates. Academic Press.

    Google Scholar
