Comparative morphology of sensilla of antennae, maxillary and labial palpi of adult Rhyzopertha dominica (F.) (Coleoptera: Bostrichidae), with specific reference to the typology and possible functions
The Journal of Basic and Applied Zoology volume 84, Article number: 14 (2023)
Abstract
Background
The lesser grain borer Rhyzopertha dominica (F.) (Coleoptera: Bostrichidae) is a cosmopolitan insect pest of stored cereal grains. In this study, the fine morphology of antennae, maxillary and labial palpi as well as the typology, morphology and distribution of associated sensilla were comprehensively examined by scanning electron microscopy.
Results
On antennae, six types of sensilla were identified, s. trichodea, s. chaetica, two subtypes of s. basiconica, s. ampullacea and s. styloconica, in addition of Böhm's sensilla (Bs). Sensilla trichodea and basiconica were the most abundant sensilla types in the club flagellomeres. Mouth parts of R. dominica were adapted for chewing; maxillary and labial palpi consisted of four and five segments, respectively. Galea of maxilla was two segments, the distal one ended with a brush like organ composed of a dense field of long s. basiconica. The sensilla of maxillary and labial palpi were long and short s. trichodea, s. basiconica, s. styloconica and s. ampullacea. Only one big sensillum digitiformium was found on the lateral side of the distal segment of the maxillary palp.
Conclusions
We summarized the validated structures of different types of sensilla on antennae and palpi of R. dominica and proposed the potential functions of them in detection of ecologically relevant stimuli.
Background
The lesser grain borer Rhyzopertha dominica (Coleoptera: Bostrichidae) is a serious pest of stored products throughout the tropics and temperate countries, either because of its ability for prolonged flight or as a result of the international trade in food products. This can cause significant economic losses in terms of nutrient depletion (Jood et al., 1996), and grain mass (Subramanyam & Hagstrum, 1995). Both larvae and adults of this insect feed on whole, sound grains and cause extensive damage (Rees, 2007). Females lay eggs on the surface of grain kernels, upon hatching; the larva enters the kernel and remains inside until maturation (Ozkaya et al., 2009). Currently, there is little information published concerning the screening of the differential structures of the sensory organs located on the antennae and mouth parts of adults of R. dominica responsible for detection of ecologically relevant stimuli lead to finding suitable habitats, food, mating opportunities and oviposition sites. However, Sawires and Elbassiouny (2019) distinguished three types of sensilla on the apical distal three segments of flagellomeres; long and short chaetica, basiconica and ampucellaceous.
Volatile semiochemicals are the principle sensory signals for insects (Mamidala et al., 2013; Wang et al., 2010). The antennae of beetles can show synergistic responses to pheromones in the presence of host plant volatiles (Giulio et al., 2012; Lopes et al., 2002; MacKay et al., 2014). The antennae of insects are the primary olfactory organ playing critical roles in food selection, intersexual communication and ovipositional site search (Zacharuk, 1985; Zhang et al., 2015). The antennal sensilla of insects have been argued to play an important role in perceiving different chemical signals related to their hosts and conspecifics (van der Goes van Naters & Carlson, 2006). It was found that the morphology and ultrastructure of antennal sensilla can be highly variable among different species of Coleoptera (Ali et al., 2016; Chi et al., 2009; Faucheux et al., 2019, 2020a, 2020b; Hao et al., 2020a; Merivee et al., 2002; Seada, 2015; Seada & Hamza, 2018). Interestingly, Chapman (2003) suggested that large numbers of sensilla should provide responses to a wider range of environmental stimuli. Previous studies investigated that the morphology and ultrastructure of antennal sensilla could be extremely variable among different species of beetles (Merivee et al., 2002; Ren et al., 2012; Volkovitsh, 2001). However, few studies have documented the structure and distribution of the antennal sensilla of beetles in the Bostrichidae, which is a large family with hundreds of species (Borowski & Wegrzynowicz, 2007; Liu & Klaus, 2011).
Understanding the feeding behavior of insects is the key to develop successful biological control programs (Wei et al., 2015). As the main feeding organs, the morphological variation of mouthparts and distribution of their sensilla is correlated with the variation of the food source as well as feeding behavior (Ma et al. 2013; Hao et al., 2020b). The sensory receptors of insect mouth parts devoted to the survival of the insect. The basic components of chewing mouthparts are the same, but they might differ due to their diverse food types and feeding preference or boring holes for laying eggs (Moon et al., 2015). Various studies have been conducted to describe the mouthpart morphology of Coleoptera (Chen et al. 2016, Hao et al., 2020a; Moon, 2015; Seada & Hamza, 2018). Characterization of the olfactory and gustatory organs of adults of R. dominica could provide an important starting point and valuable information for further physiological and behavioral studies, which can ultimately lead to developing practical monitoring and management strategies with semiochemicals.
Various studies have reported that the sensory complement is also relevant to a species’ ecological niche and involved in feeding and reproductive behavior (Zaitseva and Elizarov 1980). The purpose of this study was to examine and compare between the distribution and fine structures of the sensorial equipment found on the antennae, maxillary and labial palpi of adult R. dominica that have a key role during grain selection process. The information documented here with further studies of identified chemosensitive sensilla can provide a foundation for developing semiochemical-based management strategies of adults of R. dominica.
Methods
Insect rearing
Approximately, 100–300 adults of R. dominica 3 days old collected from stored untreated cereal grains. The insects were reared for several generations in Crops Research Institute, Agricultural Research Center, Sakha, Egypt. They were placed in 850 ml glass jars containing 400 g of wheat grains as a food source. The jars openings were covered with muslin cloth, kept in a position with rubber bands. The adults of R. dominica were maintained in the laboratory at 28 ± 2 °C, 70 ± 5% relative humidity (RH) and light: dark photoperiod of 16: 8 h. In order to obtain adult beetles, the flour was sieved to separate the beetles.
Fine structure and scanning electron microscopy
For scanning electron microscopy (SEM), whole adult insects were immersed in 70% ethanol overnight at 4 °C. Specimens were put in a series of graded solution of ethanol, from 70 to 100%, mounted on SEM stubs with double sided sticky tapes and sputter coated with gold–palladium (3:2) in a JEOL ion sputter JFC-1100E. The specimens were visualized using a scanning electron microscope (JSM-5300, UK).
The number, distribution, and morphometric characters of each sensillum type were analyzed from SEM micrographs of five individuals with imageJ program (https://imagej.nih.gov/ij/). The lengths of all types of sensilla were then analyzed from SEM micrographs. All data were reported as means and standard error of means.
Results
General morphology of the antennae
The length of antenna of the adult lesser grain borer R. dominica was 197 ± 9.4 µm. The antenna consisted of a scape (the 1st antennomere), a pedicel, and a flagellum. The flagellum was composed of eight flagellomeres, distinguished into narrow proximal funicle (fl1–fl5) and wide distal club (cl1–cl3) (Fig. 1A–B, Table 1). Two clusters of Böhm's sensilla located at the basal part of the scape and pedicel were also detected (Fig. 2A and D and Table 2).
Antennal sensillum types and distribution
Based on the morphological features, the antennal sensilla of the adult R. dominica could be identified into six types: one type of s. trichodea, one type of s. chaetica, two subtypes of s. basiconica (short coned sb1 and elongated sb2), one type of s. ampullacea, in addition of Böhm's sensilla (Bbs) (Figs. 1, 2, 3, Table 2). The density of sensilla increases from proximal to distal parts of antenna but all types of sensilla were found only on the distal three antennal club flagellomeres. The dominant types of sensilla were s. trichodea and s. basiconica, especially on the distal club flagellomeres (Figs. 1, 2, 3, 4). Sensilla trichodea were detected along all flagellar segments (Fig. 2A).
Sensilla trichodea
Sensilla trichodea were pointed hairs surrounded by a deep ditch in the cuticle and tapering only at the distal end (Length = 18.4 ± 0.26 μm and basal width = 0.69 ± 0.02 μm) (Fig. 2 and Table 2). They were randomly located on all flagellar segments and the most abundant antennal sensilla type in the last club flagellar segments of antennae (n = 98.7 ± 3.6) (Figs. 1, 2, 3, 4, Table 2). The density on the first five proximal flagellar segments (funicle) was low and increased toward the distal end of the flagellum (Figs. 3 and 4).
Sensilla basiconica
There were two subtypes of s. basiconica, bs1 and bs2, predominantly scattered along the three club flagellar segments and intermittent between s. trichodea (Figs. 3A–D and 4, Table 2).
The sensilla basiconica I (sb1, n = 38 ± 3.8) were short, curved, rod-like hairs (Length = 3.74 ± 0.03, basal width = 1.63 ± 0.02 µm) and abundant mainly at the dorsal side of club flagellomeres (Fig. 3A–D). They were parallel to the cuticle of the antenna and end with blunt tip but did not have basal sockets (Fig. 3B–D). The sensilla basiconica II, sb2 (n = 26.7 ± 2.7) were longer than s. basiconica I. They were thin, finger like hairs (Length = 5.29 ± 0.06, basal width = 0.94 ± 0.01 µm) with blunt tip, smooth cuticle and without basal socket (Figs. 3B–D and 4 and Table 2). They were distributed at the distal end of each club flagellomere (Fig. 3A–D).
Sensilla ampullacea
Each s. ampullacea was a prominent elliptical depression and central opening (basal diameter = 1.3 ± 0.05 µm). Ampullacea sensilla were found exclusively at the distal end of the third club flagellar segment (cl3) (Fig. 3C–D). Only small apertures were visible, but they could not be counted. These sensilla appear as small round openings on the cuticular surface externally (Fig. 3B–D).
Sensilla chaetica
The sensilla chaetica (n = 9 ± 0.33 per each club flagellomere) were long, thick and curved rods with longitudinal warts recessed in depressed cuticle (Length = 10.27 ± 0.27 µm, basal width = 1.29 ± 0.02 µm) (Table 2). The external surface of s. chaetica was slightly rough whereas the base of these sensilla was inserted slightly depressed into the cuticle and end with blunt tips which suggesting the gustatory function (Fig. 4). They were distributed at the periphery of each club flagellomere (Fig. 4).
Böhm's sensilla
Böhm's sensilla were spine-like cuticular structures, similar to trichoid sensilla in shape but these sensilla were sharper and much shorter in length and found in clusters without wall pores on the surface or at the tip (Fig. 2A and D). They were distributed in one or two clusters at the bases of scape and pedicel (Table 2).
Sensory organs of the mouth parts
Mouth parts of adult R. dominica are adapted for chewing and consisted of prolonged labrum, two unjointed prolonged mandibles (labrum and mandibles are forming a beak like structure), two symmetrical maxillae with a pair of four segmented maxillary palps and two double segmented galea, and one labium with a lateral pair of five segmented labial palps (Fig. 5A–D). The sensory field of the chemosensory sensilla was found to be mainly concentrated at the tip of the distal segments of both maxillary and labial palps (Fig. 5B–D).
Sensilla of labial palp
The five segments of the labial palp of adult R. dominica had numerous s. trichodea divided into two subtypes; short (st1) and long (st2) distributed around the periphery of all segments (Fig. 5A). The sensilla of the basal labial segment could not be investigated. The second segment had both subtypes of s. trichodea (st1: length = 4.4 ± 0.44 µm and n = 6 ± 0.4 and st2; length = 18.29 µm and n = 2.5 ± 0.29), in addition of many microtrichea (mt) (Fig. 5A–B). The third segment of labial palp had only short s. trichodea (st1: length = 9.93 ± 0.27 µm and n = 1.25 ± 0.25) (Table 3). Even though, the fourth segment of the labial palp had both subtypes of s. trichodea (st1: length = 6.2 ± 1.89 µm, n = 3.33 ± 0.33 and st2: length = 25.5 ± 2.46 µm, n = 8.5 ± 1.3) (Fig. 5A–B). Furthermore, the labial palp had the longer s. trichodea than maxillary palp (Fig. 5A–B). The distal segment of the labial palp was elongated, conical shaped and terminated with an apical disc. The apical disc consisted of a sensory field fringed with many s. basiconica and s. styloconica which could not be investigated as they were obscured. In addition of short s. trichodea at the external periphery of it (st1: length = 12.1 ± 2.38 µm, n = 18.8 ± 1.85) (Fig. 5A–B).
Sensilla of maxillary palp
The first three segments of the maxillary palp of adult R. dominica were cylindrical in shape (Fig. 5A, C and D), while the distal segment was conical in shape and their cuticular walls presented striations resembling ‘fishbone’ patterns (Fig. 5D).
The sensilla of the basal segment of the maxillary palp were difficult to investigate. The second segment of the maxillary palp had long s. trichodea (st2: length = 23.35 ± 3.2 µm, width = 0.9 ± 0.3 µm, n = 17 ± 1.07) (Fig. 5A, B and D). The third segment had ventral s. trichodea (st1: length = 7.58 ± 0.69 µm, width = 0.67 ± 0.2 µm, n = 10.7 ± 0.7). The distal segment of the maxillary palp had short s. trichodea (st1: length = 10.23 ± 0.5 µm, width = 0.72 ± 0.1 µm, n = 18 ± 1.38) (Fig. 6 A). In addition of a single big sensillum digitiformium at the dorsal region (length = 9.28 ± 0.04 µm, middle width = 4.28 ± 0.01 µm) (Fig. 5D, 6A and C). The s. digitiformium was rabbit ear-shaped with cuticular surface showed a shallow concavity, with small longitudinal grooves in the cuticle (Fig. 6A, C and D). It was parallel to the dorsal region of the distal segment of the maxillary palp on the distal extremity.
Sensilla trichodea were distributed at the ventral region of the maxillary palp, they were hairs sharply tapering at the tip and recessed in a depression in the cuticle (Fig. 6C).
The apical tip of the distal segment of the maxillary palp was a concave disc carried a sensory field (ssf) consisted of s. basiconica (length = 0.9 ± 0.07 µm, width = 0.34 ± 0.01 µm, n = 12.8 ± 0.7) and s. styloconica (length = 0.49 ± 0.07 µm, width = 1.05 ± 0.15 µm, n = 10.8 ± 0.9). Sensilla basiconica (sb) and styloconica (sst) were intermingled and distributed around the perimeter of the sensory field (Fig. 6B). Sensilla basiconica were pegs tapered from the base to the apex and the apical extremity formed a triangular shape (Fig. 6B), their structure may dedicate the olfactory or gustatory functions. Sensilla styloconica were peg-like structures, set on top of conical cuticular styles attached to the cuticle ended with apical nipples, with a basal diameter of 2.18 ± 0.3 μm (Fig. 6B). In addition, two sensilla ampulacea at the periphery of the sensory field of the apical segment of the maxillary palp were detected.
The galea of maxilla consisted of two segments (Fig. 5A and C), the distal one was fringed with a tuft of long s. basiconica (length = 20.4 ± 1.13 µm, basal diameter = 0.87 ± 0.01 µm, n = 42.3 ± 2.28). These sensilla were thick, smooth and curved rods with blunt tips.
Discussion
In this study, we focused on the morphology, structure as well as the distribution pattern of the sensilla found on antennae, maxillary and labial palpi of the adult lesser grain borer, R. dominica. These organs were significantly equipped with more sensory sensilla which are involved in the chemical communication during its life. Interspecific and intraspecific chemical interactions are generally mediated by pheromones and allelochemicals (Song et al., 2017). Stored grain pests, including R. dominica mainly depend on the chemical cues to detect, infest and ingest their food (Oehlschlager et al., 1988).
Sensilla of antennae
In this study, five types of sensilla, including s. trichodea, two subtypes of s. basiconica, s. chaetica, s. ampullacea and Bӧhm's bristles, were identified in details in adult R. dominica by scanning electron microscope (SEM). The antennal sensilla are important sensory organs for insect communication and survival, and they are in direct contact with their environment (Nakanishi et al., 2009). The relative number and diversity of sensilla found in antennae of R. dominica are close in magnitude to those reported previously for other members of Coleoptera, such as Agrilus mali (Coleoptera: Buprestidae) (Yi et al., 2016), Callosobruchus chinensis (L.), C. maculatus (F.) (Coleoptera: Bruchidae) (Hu et al., 2009) and Tribolium castenium (Coleoptera: Tenebrionidae) (Seada & Hamza, 2018).
In the present study, Bӧhm's sensilla (BBs) were found only on the first two segments of the antennae which was in accordance with other studies. They had a typical feature of mechano-sensitive receptors that perceive the common pressure on the cuticle produced by the movement of the antennae (Hao et al., 2020a; Merivee et al., 2002). Böhm's sensilla were classified by Schneider (1964) as s. chaetica, but these setae were shorter and sharper than s. chaetica which were arranged in clusters at the base of the scape and pedicel.
The s. trichodea of antennae of adult R. dominica were abundant at the three distal club flagellar segments, suggesting that these sensilla were serving as olfactory receptors. They were widely believed to be olfactory sensilla (Yang et al., 2009). Typically, Hippodamia convergens (Coccinellidae) did not respond to odors when their s. trichodea were removed, which deduced their responsibility for long-range olfactory reception (Hamilton et al., 1999). In Rhynchophorus palmarum (Coleoptera: Carabidae), s. trichodea were described as chemoreceptors to sex or aggregation pheromone (Merivee et al., 2002). Sensilla trichodea were common types in antennae of different beetles and densely located on the tip of the flagellum (Chi et al., 2009; Srivastava & Omkar, 2003). Sensilla similar to s. trichodea of this study had been described in different beetles, e.g. Bembidion lampros (Hbst.), Dastarcus helophoroides (Fairmaire), and Agrilus mali (Ploomi et al., 2003; Ren et al., 2012; Yi et al., 2016).
In the current study, s. basiconica (sb1-sb2) were the second most frequent type found in the three club flagellar segments (cl1–cl3) of adult R. dominica. In contrary to s. trichodea, both subtypes of s. basiconica were found only on the dorsal side of all club flagellar segments. Basiconic sensilla of antennae of R. dominica were straight and smooth walled with blunt (sb1) or sharp tips (sb2) without setting in basal sockets. Based on the porous characteristics and previous publications, the two subtypes of s. basiconica of R. dominica may perform a chemo-receptive function (Lopes et al., 2002; Zacharuk, 1985). Commonly, aporous sensilla work as mechanoreceptors, thermoreceptors, or hygroreceptors receptors while porous sensilla work as chemoreceptors (e.g. olfactory and gustatory) (Keil, 1999; McIver, 1985). Similarly, antennal s. basiconica of Tetrigus lewisi and Callosobruchus chinensis considered to play critical roles in odor sensing for searching relevant habitat and food resources (Ren et al., 2014; Wang et al., 2018).
Indeed, the structure characteristics of s. basiconica vary greatly among different insect groups, however, all s. basiconica share common features; i.e. lower in height and have much more wall pores in comparison to trichoid sensilla (Shields, 2004). The basiconic sensilla in this study were similar in external morphology to some basiconic sensilla found in other beetles, i.e. Agrilus mali, A. planipennis, and Dastarcus helophoroides (Fairmaire) (Ren et al., 2012; Yi et al., 2016). The basiconic sensilla of Phoracantha semipunctata (Coleoptera: Cerambycidae) were found to be tuned and specialized for a particular set of host and non-host volatiles (Lopes et al., 2002). Ali et al. (2016) reported that the basiconic sensilla of distal three flagellar segments of Tribolium castaneum (Coleoptera: Tenebrionidae) play a major role in the fast location of food sources, whereas the removal of the last three flagellar segments increased the time spent in making a choice.
As the most abundant among all sensilla classes in our study, external structure of trichoid and basiconic sensilla might represent the major portion of the olfactory repertoire on the antennae of R. dominica. Thus, they could be important for long-range chemosensory perception of environmental cues. Typically, s. trichodea and s. basiconica were the basic types that distributed on the antennae of all studied coleopteran species (Hao et al., 2020a).
In the current study, s. ampullacea were recessed in a pit at the dorsal region of the scape and flagellum of antennae of R. dominica and their morphology was noticeably distinct from other sensilla types. This is not optimal for receiving chemical stimuli, but is likely a necessary adaptation to prevent desiccation (Kristoffersen et al., 2006). Accordingly, s. ampullacea might also participate in the processes of hygro- and thermoreception (Kleineidam & Tautz, 1996; Ruchty et al., 2010) and the perception of CO2 (Kleineidam & Roces, 2000). Correlated to the abundance of hair sensilla, s. ampullacea have been found in low numbers on the antennal club of R. dominica (Sawires & Elbassiouny, 2019) and other insects as well (Renthal et al., 2003; Romani et al., 2010). Hao et al. (2020a) found that s. coeloconica of Hippodamia variegata (Coleoptera: Coccinellidae) were small pit organs, which were similar to s. ampullacea that were observed in our study. Similarly, sensilla cavity in Callosobruchus septempunctata (Srivastava & Omkar, 2003) and C. chinensis (Wang et al., 2018) have the same structure of s. ampullacea of R. dominica.
In the present study, s. chaetica found on the antennae of adult R. dominica were mainly distributed on the distal region of the club flagellomeres (cl1–cl3) with a few number and surrounded by a deep and thick circular furrow coupled with a wall around. Characterized by their thick wall and specific distal location might suggest a contact-chemoreceptive function (Ryan, 2002). Similarly, s. chaetica of Psylliodes chrysocephala were suggested to be contact chemosensilla responded to chemicals presented in plant surface waxes (Isidoro, 1998). Borg and Norris (1971) assumed that s.chaetica found on the antennae of Scolytus multistriatus were mechanoreceptors allowing the insect to explore the position of the antenna in relation to the surrounding. Sensilla chaetica were also common on the antennae of many other insects (Chi et al., 2009; Hao et al., 2020a; Seada & Hamza, 2018; Wei et al., 2015).
palpi
It is worth noting that, there is a great species diversity and very broad range of trophic relations and modes of feeding in Coleoptera. In our study, both maxillary and labial palps of adult R. dominica have similar sets of numerous sensilla; however the labial palp carried more longer sensilla trichodea. Similarly, the sensory organs of the maxillary and labial palps of Dytiscidae and Dermestidae have very similar groups of sensilla (Alekseev et al., 2006). An increase in the number of sensilla in the sensory organs should apparently facilitate a better perception of information from the surrounding (Merivee et al., 2002). Various studies described the morphology of the mouthparts of Coleoptera insects (Hao et al., 2020b; Moon, 2015; Seada & Hamza, 2018), but no reports have focused on R. dominica.
The data of the current study revealed that sets of sensilla present on both maxillary and labial palpi of adult R. dominica had different types of sensilla, among them, two subtypes of s. trichodea (st1 and st2), which were more widespread and abundant all around the palpal segments. In addition, specialized sensory apical area at the last distal segment of the maxillary and labial palpi had different kinds of s. basiconica, s. styloconica and ampullacea. Despite, they have been distinguished but could not be counted in the labial palp as they were concealed inside. In contrast, there was only one big sensillum digitiformium on the lateral side of the distal segment of the maxillary palp. External structure of trichoid sensilla; sharp tips and flexible sockets might dedicate the mechanosensory function. Seo and Youn (2000) found that the maxillary and labial palpi of Hippodamia variegata (Coleoptera: Coccinellidae) were mainly used as mechanoreceptors. Furthermore, s. trichodea in this species appeared to be identical to those found on the labial palp of Pyrrhocoris sibiricus (Wang & Dai, 2017). However, the similarity of the s. digitiformium to morphologically or physiologically characterized s. auricillica in other insects might suggest the olfactory function. Sensilla digitiformium have been described in different insect species, i.e. on the tip of the ovipositor of Dyseriocrania subpurpurella (Lepidoptera: Eriocraniidae) (Faucheux, 2008), on the labial palps of Ctenicera destructor (Coleoptera: Elatridae) which responded electrophysiologically to contact and vibratory stimuli (Zacharuk et al., 1977). Furthermore, sensilla digitiformia were suggested to be sensitive to temperature (Devitt & Smith, 1982). In Helicoverpa armigera caterpillars the digitiformia sensilla on the maxillary palp was probable candidate for the CO2-receptor (Keil, 1996). It has been also found also on the maxillary palp of larvae of spodoptera littoralis (Awad et al., 2015).
The galea of maxillae of R. dominica had a dense tuft of long s. basiconica these sensilla were curved with blunt tips and smooth surfaces which assume a gustatory or olfactory functions. Zacharuk (1985) proposed that s. basiconica and s. styloconica correspond to the uniporous sensilla with a sculptured porous point through the cuticle. Behavioral investigations on herbivorous insects indicated the significance of the gustatory sensilla of the galea of maxillae on the feeding process (de Boer, 2006). In contrast, a single type of an olfactory basiconicum sensillum on the last distal segment of the maxillary palp of adult Toxorhynchites brevipalpis (Diptera: Culicidae) had been found (McIver & Siemicki, 1984).
Correspondingly, the species that have a limited range of diet like R. dominica have a smaller number of sensilla on the palpi. In preceding studies, functional types of olfactory and gustatory sensilla were found on the palpi of different insects (Guo et al., 2018; Zhao et al., 2013).
Conclusions
This study is the first to characterize the sensilla found on mouth parts of an important invasive beetle; R. dominica. Differences in the numbers and distribution of various sensilla in different organs of the beetle like antennae, the main organ for olfaction, and palpi which responsible for the taste of food were also evaluated. Such studies would clarify the expected functional roles of various insect sensilla in sensing pheromones, and host and non-host chemicals, which could ultimately lead to developing novel efficient control strategies.
Availability of data and materials
The datasets used during the current study are available from the corresponding author on reasonable request.
Abbreviations
- amp:
-
Sensilla ampullaceal
- ant:
-
Antenna
- Bbs:
-
Böhm's sensilla
- cl1–cl3:
-
Distal club flagellomeres
- gl:
-
Galea of maxilla
- fl1–fl5:
-
Basal flagellomeres
- lb:
-
Labrum
- lp:
-
Labial palp
- md:
-
Mandible
- mp:
-
Maxillary palp
- mt:
-
Microtrichea
- pe:
-
Pedicel
- sb1 and sb2:
-
Sensilla basiconica
- sc:
-
The scape
- SD:
-
Sensilla digitiformium
- SEM:
-
Scanning electron microscopy
- st1 and st2:
-
Sensilla trichodea
- ssf:
-
Sensory field
- sst:
-
Sensilla styloconica
References
Alekseev, M., Sinitsina, E., & Chaika, S. (2006). Sensory organs of the antennae and mouth parts of beetle larvae (Coleoptera). Entomological Review, 86, 638–648. https://doi.org/10.1134/S0013873806060042
Ali, S., Diakite, M., Ali, S., & Wang, M. (2016). Effects of the antennal sensilla distribution pattern on the behavioral responses of Tribolium castaneum (Coleoptera: Tenebrionidae). Florida Entomologist, 99(1), 52–59. https://doi.org/10.1653/024.099.0110
Awad, A. A., Korayem, A. M., Amr, M. A., & Aboelela, R. A. (2015). The effect of different host plants on the antennal and mouthparts sensilla of the larvae of Spodoptera littoralis (Lepidoptera: Noctuidae). Egyptian Academic Journal of Biological Sciences, 8(1), 61–72. https://doi.org/10.21608/eajbs.2016.6
Borg, T. K., & Norris, D. M. (1971). Ultrastructure of sensory receptors on the antennae of Scolytus multistriatus (Marsh.). Zeitschrift Für Zellforschung Und Mikroskopische Anatomie, 113, 13–28. https://doi.org/10.1007/BF00331198.10.1007/BF00331198
Chapman, R. F. (2003). Contact chemoreception in feeding by phytophagous insect. Annual Review of Entomology., 48, 455–484. https://doi.org/10.1146/annurev.ento.48.091801.112629
Chen, F., Zhang, C. N. & Dai, W. (2016). Fine structure and sensory apparatus of the mouthparts of the maize weevil, Sitophilus zeamais Motschulsky (Coleoptera: Curculionoidea: Dryophthoridae). Annals of the Entomological Society of America, 109, 881–889. https://doi.org/10.1093/aesa/saw054
Chi, D. F., Wang, G. L., Liu, J. W., Wu, Q. Y., & Zhu, Y. P. (2009). Antennal morphology and sensilla of Asian multicolored ladybird beetles, Harmonia axyridis Pallas (Coleoptera: Coccinellidae). Entomological News, 120(22), 137–152. https://doi.org/10.3157/021.120.0203
De Boer, G. (2006). The role of the antennae and maxillary palps in mediating food preference by larvae of the tobacco hornworm, Manduca sexta. Entomologia Experimentalis et Applicata, 119, 29–38. https://doi.org/10.1111/j.1570-7458.2006.0039
Devitt, B. D., & Smith, J. J. B. (1982). Morphology and fine structure of mouthpart sensilla in the dark-sided cutworm Euxoa messoria (Harris) (Lepidoptera: Noctuidae). International Journal of Insect Morphology and Embryology, 11, 255–270. https://doi.org/10.1016/0020-7322(82)90015-0
Faucheux, M. J. (2008). Sensilla digitiformia and campaniformia on the tip of the piercing ovipositor of Dyseriocrania subpurpurella (Haworth 1828) (Lepidoptera: Eriocraniidae). Annales De La Société Entomologique De France (NS), 44(3), 311–314. https://doi.org/10.1080/00379271.2008.10697568
Faucheux, M. J., Hamidi, R., Mercadal, M., Thomas, M., & Frérot, B. (2019). Antennal sensilla of male and female of the nut weevil Curculio nucum Linnaeus 1758 (Coleoptera: Curculionidae). Annales De La Société Entomologique De France (n.s.), 55(5), 395–409.
Faucheux, M. J., Németh, T., Hoffmannova, J., & Kundrata, R. (2020b). Scanning electron microscopy reveals the antennal micromorphology of Lamprodila (Palmar) festiva (Coleoptera: Buprestidae), an invasive pest of ornamental Cupressaceae in Western Palaearctic. Biology, 9, 375. https://doi.org/10.3390/biology9110375
Faucheux, M. J., Németh, T., & Kundrata, R. (2020a). Comparative antennal morphology of Agriotes (Coleoptera: Elateridae) with special reference to the typology and possible functions of sensilla. InSects, 11, 137. https://doi.org/10.3390/insects11020137
Giulio, A. D., Maurizi, E., Stacconi, M. V. R., & Romani, R. (2012). Functional structure of antennal sensilla in the myrmecophilous beetle Paussus favieri (Coleoptera, Carabidae, Paussini). Micron, 43, 705–719. https://doi.org/10.1016/j.micron.2011.10.013
Guo, M., Chen, Q., Liu, Y., Wang, G., & Han, Z. (2018). Chemoreception of mouthparts: Sensilla morphology and discovery of chemosensory genes in proboscis and labial palps of adult Helicoverpa armigera (Lepidoptera: Noctuidae). Frontiers in Physiology, 9, 970. https://doi.org/10.3389/fphys.2018.00970
Hamilton, R. M., Dogan, E. B., Schaalje, G. B., & Booth, G. M. (1999). Olfactory response of the lady beetle Hippodamia convergens (Coleoptera: Coccinellidae) to prey related odors, including a scanning electron microscopy study of the antennal sensilla. Environmental Entomology, 28(5), 812–822. https://doi.org/10.1093/ee/28.5.812
Hao, Y. N., Sun, Y. X., & Liu, C. Z. (2020a). Functional morphology of antennae and sensilla of Hippodamia variegata (Coleoptera: Coccinellidae). PLoS ONE, 15(8), e0237452. https://doi.org/10.1371/journal.pone.0237452
Hao, Y. N., Sun, Y. X., & Liu, C. Z. (2020b). Functional morphology of the mouthparts of lady beetle Coccinella transversoguttata (Coleoptera: Coccinellidae), with reference to their feeding mechanism. Journal of Morphology, 280(5), 701–711. https://doi.org/10.1002/jmor.20976
Hu, F., Zhang, G. N., & Wang, J. J. (2009). Scanning electron microscopy studies of antennal sensilla of bruchid beetles, Callosobruchus chinensis (L.) and Callosobruchus maculatus (F.) (Coleoptera: Bruchidae). Micron, 40(3), 320–326. https://doi.org/10.1016/j.micron.2008.11.001
Isidoro, N., Bartlet, E., Ziesmann, J., & Williams, I. H. (1998). Antennal contact chemosensilla in Psylliodes chrysocephala responding to cruciferous allelochemicals. Physiological Entomology, 23(2), 131–138. https://doi.org/10.1046/j.1365-3032.1998.232066.x
Jood, S., Kapoor, A. C., & Singh, R. (1996). Effects of insect infestation and storage on lipids of cereal grains. Journal of Agriculture and Food Chemistry, 44, 1502–1506. https://doi.org/10.1021/jf950270e
Keil, T. A. (1996). Sensilla on the maxillary palps of Helicoverpa armigera caterpillars: In search of the CO(2)-receptor. Tissue and Cell, 28(6), 703–717. https://doi.org/10.1016/S0040-8166(96)80073-5
Keil, T. A. (1999). Morphology and development of the peripheral olfactory organs. In B. S. Hansson (Ed.), Insect olfaction (pp. 5–47). Springer, Berlin Heidelberg.
Kleineidam, C., & Roces, F. (2000). Carbon dioxide concentrations and nest ventilation in nests of the leaf-cutting ant Atta vollenweideri. Insects Sociaux, 47, 241–248. https://doi.org/10.1007/PL00001710
Kleineidam, C., & Tautz, J. (1996). Perception of carbon dioxide and other “air-condition” parameters in the leaf cutting ant Atta cephalotes. Naturwissenschaften, 83, 566–568. https://doi.org/10.1007/BF01141981
Kristoffersen, L., Hallberg, E., Wallén, R., & Anderbrant, O. (2006). Sparse sensillar array on Trioza apicalis (Homoptera: Triozidae) antennae—an adaptation to high stimulus levels? Arthropod Structure and Development, 35, 85–92. https://doi.org/10.1016/j.asd.2006.04.001
Liu, L. Y., & Schonitzer, K. (2011). Phylogenetic analysis of the family Bostrichidae auct. at suprageneric levels. Mitteilungen Münchner Entomologische Gesellschaft., 101, 99–132.
Lopes, O., Barata, E. N., Mustaparta, H., & Arau´jo, J. (2002). Structure of antennal sensilla basiconica and their detection of plant volatiles in the eucalyptus woodborer, Phoracantha semipunctata Fabricius (Coleoptera: Cerambycidae). Arthropod Structure and Development, 31(1), 1–13. https://doi.org/10.1016/S1467-8039(02)00011-7
Ma, N., Huang, J. & Hua, B. Z. (2013). Functional morphology and sexual dimorphism of mouthparts of the short faced scorpionfly Panorpodes kuandianensis (Mecoptera: Panorpodidae). PLoS ONE, 8, 1453–1456. https://doi.org/10.1371/journal.pone.0060351
MacKay, C. A., Sweeney, J. D., & Hillier, N. K. (2014). Morphology of antennal sensilla of the brown spruce longhorn beetle, Tetropium fuscum (Fabr.) (Coleoptera: Cerambycidae). Arthropod Structure and Development, 43, 469–475.
Mamidala, P., Wijeratne, A. J., Wijeratne, S., Poland, T., Qazi, S. S., Doucet, D., Cusson, M., Beliveau, C., & Mittapalli, O. (2013). Identification of odorprocessing genes in the emerald ash borer, Agrilus planipennis. PLoS ONE, 8, e56555.
McIver, S. B. (1985). Mechanoreception. In G. A. Kerkut & L. I. Gilbert (Eds.), Comprehensive insect physiology biochemistry and pharmacology (Vol. 6, pp. 71–132). Pergamon Press. https://doi.org/10.1016/0020-1790(85)90131-3
McIver, S. B., & Siemicki, R. (1984). Fine structure of pegs on the maxillary palps of adult Toxorhynchites brevipalpis Theobald (Diptera: Culicidae). International Journal of Insect Morphology and Embryology, 13, 11–20. https://doi.org/10.1016/0020-7322(84)90028-X
Merivee, E., Ploomi, A., Rahi, M., Bresciani, J., Ravn, H. P., & Luik, A. (2002). Antennal sensilla of the ground beetle Bembidionpro perans Steph. (Coleoptera: Carabidae). Micron, 33(5), 429–440. https://doi.org/10.1016/s0968-4328(02)00003-3
Moon, M. J. (2015). Microstructure of mandibulate mouthparts in the greater rice weevil, Sitophilus zeamais (Coleoptera: Curculionidae). Entomological Research. https://doi.org/10.1111/1748-5967.12086
Nakanishi, A., Nishino, H., Watanabe, H., Yokohari, F. & Nishikawa, M. (2009). Sexspecific antennal sensory system in the ant Camponotus japonicus: Structure and distribution of sensilla on the flagellum. Cell Tissue Research, 338, 79–97. https://doi.org/10.1007/s00441-009-0863-1
Oehlschlager, A. C., Pierce, A. M., & Pierce, H. D. (1988). Chemical communication in cucujid grain beetles. Journal of Chemical Ecology, 14, 2071–2098. https://doi.org/10.1007/BF01014251.
Ozkaya, H., Ozkaya, B., & Colakoglu, A. S. (2009). Technological properties of a variety of soft and hard bread wheat infested by Rhyzopertha dominica (F.) and Tribolium confusum du Val. Journal of Food Agriculture & Environment, 7, 166–179. http://www.isfae.org/scientificjourna
Ploomi, A., Merivee, E., Rahi, M., Bresciani, J., Ravn, H. P., Luik, A., & Sammelselg, V. (2003). Antennals ensillain ground beetles (Coleoptera:Carabidae). Agronomy Research, 1, 221–228. Corpus ID:87631847.
Rees, S. S., Murphy, A. J., Watsford, M. L., McLachlan, K. A., & Coutts, A. J. (2007). Effects of proprioceptive neuromuscular facilitation stretching on stiffness and force producing characteristics of the ankle in active women. Journal of Strength and Conditioning Research, 21(2), 572–577. https://doi.org/10.1519/R-20175.1
Ren, L., Shi, J., Zhang, Y., & Luo, Y. (2012). Antennal morphology and sensillar ultrastructure of Dastarcus helophoroides (Fairmaire) (Coleoptera: Bothrideridae). Micron, 43, 921–928. https://doi.org/10.1016/j.micron.2012.03.005
Ren, L. L., Wu, Y., Shi, J., Zhang, L., & Luo, Y. Q. (2014). Antenna morphology and sensilla ultrastructure of Tetrigus lewisi Candèze (Coleoptera: Elateridae). Micron, 60, 29–38. https://doi.org/10.1016/j.micron.2014.01.005. PMID: 24602269.
Renthal, R., Velasquez, D., Olmos, D., Hampton, J., & Wergin, W. P. (2003). Structure and distribution of antennal sensilla of the red imported fire ant. Micron, 34, 405–413. https://doi.org/10.1016/S0968-4328(03)00050-7
Romani, R., Isidoro, N., & Bin, F. (2010). Antennal structures used in communication by egg parasitoids. In F. L. Consoli, J. R. P. Parra, & R. A. Zucchi (Eds.), Progress in biological control. (Vol. 9). Springer. https://doi.org/10.1007/978-1-4020-9110-0_3
Ruchty, M., Roces, F., & Kleineidam, C. (2010). Detection of minute temperature transients by thermosensitive neurons in ants. Journal of Neurophysiology, 104(3), 1249–1256. https://doi.org/10.1152/jn.00390.2010
Sawires, S., & Elbassiouny, A. (2019). Effect of Gamma irradiation on morphology of antennal sensilla of Rhyzopertha dominica (Coleoptera: Bostrichidae). Journal of Radiation Research and Applied Sciences, 12, 234–239. https://doi.org/10.1080/16878507.2019.1594093
Schneider, D. (1964). Insect antennae. Annual Review of Entomology., 9, 103–122. https://doi.org/10.1146/annurev.en.09.010164.000535
Seada, M. A., & Hamza, A. M. (2018). Differential morphology of the sensory sensilla and antennae, palpi, foretarsi and ovipositor of adult Tribolium castaneum (Herbst) (Coleoptera: Tenebrionidae). Annals of Agricultural Science, 63, 1–8. https://doi.org/10.1016/j.aoas.2018.02.001
Seada, M. A., Ignell, R., & Anderson, P. (2015). Morphology and distribution of ovipositor sensilla of female cotton leaf worm Spodoptera littoralis (Lepidoptera: Noctuidae), and evidence for gustatory function. Entomological Science, 19, 9–19. https://doi.org/10.1111/ens.12160.Seo
Seo, M. J., & Youn, Y. N. (2000). The Asian ladybird, Harmonia axyridis, as biological control agents: I. Predacious behavior and feeding ability. Korean Journal of Applied Entomology, 39, 59–71. Corpus ID: 82482062.
Song, L. M., Wang, X. M., Huang, J. P., Zhu, F., Jiang, X., Zhang, S. G., & Ban, L. P. (2017). Ultrastructure and morphology of antennal sensilla of the adult diving beetle Cybister japonicus Sharp. PLoS ONE, 12(3), e0174643. https://doi.org/10.1371/journal.pone.0174643
Srivastava, S., & Omkar, M. (2003). Scanning electron microscopy of antennae of Coccinella septempunctata (Coccinellidae: Coleoptera). Insect Science, 10(4), 271–279. https://doi.org/10.1111/j.1744-7917
Subramanyam, B., & Hagstrum, D. W. (1995). Resistance measurement and management. In B. Subramanyam & D. W. Hagstrum (Eds.), Integrated management of insects in stored products (pp. 331–397). Marcel Dekker. https://doi.org/10.1201/9780203750612-8
van der Goes van Naters, W., & Carlson, J. R. (2006). Insects as chemosensors of humans and crops. Nature, 444, 302–307. https://doi.org/10.1038/nature05403
Volkovitsh, M. G. (2001). The comparative morphology of antennal structures in Buprestidae (Coleoptera): evolutionary trends, taxonomic and phylogenetic implications (Part 1). Acta Musei Moraviae-Scientiae Biologicae (brno)., 86, 43–169.
Wang, H., Zheng, H., Zhang, Y., & Zhang, X. (2018). Morphology and distribution of antennal, maxillary palp and labial palp sensilla of the adult bruchid beetles, Callosobruchus chinensis (L.) (Coleoptera: Bruchidae). Entomological Research, 48(6), 466–479. https://doi.org/10.1111/1748-5967.12296
Wang, X. Y., Yang, Z. Q., Gould, J. R., Zhang, Y. N., Liu, G. J., & Liu, E. S. (2010). The biology and ecology of the emerald ash borer, Agrilus planipennis in China. Journal of Insect Science, 10, 128. https://doi.org/10.1673/031.010.12801
Wang, Y., & Dai, W. (2017). Fine structure of mouthparts and feeding performance of Pyrrhocoris sibiricus Kuschakevich with remarks on the specialization of sensilla and stylets for seed feeding. PLoS ONE, 12(5), e0177209. https://doi.org/10.1371/journal.pone.0177209
Wei, C. B., Ren, X., Chen, X., Zhou, W., & Wang, Z. (2015). Scanning electron microscope observations on the antennal sensilla of two stored grain pests Trogoderma granarium and Trogoderma variabile (Coleoptera: Dermestidae). The Florida Entomologist, 98, 140–148. https://doi.org/10.1653/024.098.0124
Yang, H., Yan, S. C., & Liu, D. (2009). Ultrastructural observations on antennal sensilla of Coleophora obducta (Meyrick) (Lepidoptera: Coleophoridae). Micron, 40, 231–238. https://doi.org/10.1016/j.micron.2008.08.002
Yi, Z., Liu, D., Cui, X., & Shang, Z. (2016). Morphology and ultrastructure of antennal sensilla in male and female Agrilus mali (Coleoptera: Buprestidae). Journal of Insect Science, 16(1), 87. https://doi.org/10.1093/jisesa/iew073
Zacharuk, R. Y. (1985). Antennae and sensilla. Pergamon PressIn G. A. Kerkut & L. I. Gilbert (Eds.), Comprehensive Insect Physiology, Biochemistry, and Pharmacology (Vol. 6, pp. 1–69). United Kingdom: Oxford.
Zacharuk, R. Y., Albert, P. J., & Bellamy, F. W. (1977). Ultrastructure and function of digitiform sensilla on the labial palp of a larval elaterid (Coleoptera). Canadian Journal of Zoology, 55, 569–578. https://doi.org/10.1139/z77-072
Zhang, Y., Ren, L., Zhang, L., & Luo, Y. (2015). Ultrastructure of antennal and posterior abdominal sensilla in Chlorophorus caragana females. Micron, 75, 45–57. https://doi.org/10.1016/j.micron.2015.04.014
Zhao, X. C., Tang, Q. B., Berg, B. G., Liu, Y., Wang, Y. R., & Yan, F. M. (2013). Fine structure and primary sensory projections of sensilla located in the labial palp pit organ of Helicoverpa armigera (Insecta). Cell and Tissue Research, 353, 399–408. https://doi.org/10.1007/s00441-013-1657-z
Borowski, J., & Werzynowicz, P. (2007). World catalogue of Bostrichidae (Coleoptera). Wydawnictwo Mantis, Olsztyn, Poland. Corpus ID: 160220464.
Ryan, M.F. (ed.). (2002). “The chemoreceptive organs: structural aspects”, In Insect Chemoreception: Fundamental and Applied (Dordrecht: Springer), 113–139. https://doi.org/10.1007/0-306-47581-2_4.
Shields, V.D.C. (2004). Ultrastructure of insect sensilla. Encyclopedia of Entomology. Springer Netherlands. 4009–4023. https://doi.org/10.1007/978-1-4020-6359-6_2295.
Zaitseva, G. A. & Elizarov, Y. A. (1980). External ultramorphology of chemoreceptors in dermestidae (Coleoptera). Zoologicheskii Zhurnal, 59(3), 388–395
